XXD 2212 1400KV Motor+HW30A ESC+K-power Servos+Propeller

Motor Specification:

Brand Name: XXD

Item Name: XXD A2212 KV1400 Brushless Motor

Item NO.: XXD A2212

Dimensions: 27.8*27mm

Shaft Diameter: 3.17mm

Max Efficiency: 80%

Max Efficiency Current: 4-10A (>75%)

Current Capacity: 12A/60s

No Load Current @ 10V: 0.5A

No. Of Cells: 2-3 Li-Poly

Weight: 47g

KV: 1400

ESC Specification:

Brand Name: XXD

Power input: 5.6V - 16.8V (2-3 cells Li-Poly, OR 5-12 cells Ni-MH Ni-MH / Ni-Cd battery)

BEC: 2A

Constant current: 30A (Max 40A less than 10 seconds)

Weight: 25g

Dimensions: 45 x 24 x 11mm

Features:

Safe power function:regardless of the throttle stick in any position the motor will not start immediately

Throttle Calibration function:Adapt to different remote throttle travel difference, improve throttle response linearity, with a smooth, delicate feel and excellent speed linear speed

Low Voltage Protection Mode ,Low-voltage protection threshold

Servo Specification:

Brand Name: K-Power

Item Name: P0090

Color: Blue

Weight (grams): 9g

Size: About 32 x 12 x 30mm

Servo Motor Type: Brushless 3 pole

Bearing Type: None

Gear Type: Plastic POM

Servo Case: Hard Plastic

Wire Length (cm): 27

Voltage: 4.8V-6.0V

Speed (6.0v) sec/60°: 0.09

Speed (4.8v) sec/60°: 0.1

Torque (6.0v) kg-cm: 1.8

Torque (4.8v) kg-cm: 1.6

Dead Band Width: 8 usec

Neutral Position: 1500 usec

Usage: Used for RC small planes, helis, boats

Features:

Perfect Low Budget with High Quality servo in 9 grams weight.

Use Metal Gear for Motor and Plastic POM material for other gears.

Has 270mm servo cable (no need to add servo cable extension)

Has TRUE data, easily run at Stall Current at 2.0Amps in 6.0 Volts.

Package Included:
1x XXD 2212 1400KV Motor
1 x XXD HW30A ESC
2 x K-power P0090 Servos
2 x EP8060 Propellers
1 x Motor Holder
3 x Spann
